Made of solid hard metal, TiN-TiAlN coating, with Weldon shank, Shaft tolerance h6, According to factory standard, Nominal size Ø 6 - 20 mm, Number of teeth 4 - 5, With protective chamfer, Milling with axial internal cooling, Extra long version, End mill with unequal helix angle 38/42°, End mill cutting edge tolerance h10 (according to ISO 286 fit system)
Secondary application: Steel (ISO-P), Main application: Stainless steel (ISO M), Secondary application: Cast materials (ISO K), Secondary application: Non-ferrous metals (ISO N), Main application: Superalloys (ISO S), For trimming / hobbing, For shoulder milling, For dynamic milling

Application
For trochoidal machining. Machining depths up to 4 x diameter (d1).
Features
Newly developed geometry with chip breakers. Low-vibration machining. Internal coolant supply, exit axial (ICA)
